ROADVISION REVOLVER MICRO BEACON RB112Y

Roadvision’s RB112 Series compact 360° high intensity beacons are at the forefront of automotive lighting technology….. Featuring state-of-the art LED technology, the REVOLVER Series of Roadvision LED beacons are specifically designed and engineered to not only meet, but exceed Australian and international regulations. With a tough Aluminium housing and impact resistant polycarbonate lens, the RB112 Series are built to last in even the toughest conditions. Featuring 32 SMD LED’s and with 10 selectable flash patterns including single, double, triple, quad & simulated rotating The RB112 Series are the perfect LED beacon for a wide range of industrial applications. -Compact low profile 10 function 360° high intensity beacons -Single, double, triple, quad & simulated rotating flash patterns -Multi-volt 10-30V input & low current draw -32 SMD LED’s produce 28W -100,000 hour rated LED lifespan -Maintenance free solid state technology -Tough polycarbonate lens & alluminium body -Waterproof IP67 rated and vibration proof -Compact low profile 112 x 48mm body -Available in 3 hole fixed, magnetic or DIN Pole mounts EMC, ECE R10 & SAE J845 class 1 approved Specifications Lens – Material Polycarbonate Light Source 32 SMD LED’s Current Draw Amps 1.9A @ 13.8V Wiring red: ve, blue: -ve, grn: pattern Warranty 5 Years Approvals EMC, ECE R10 & SAE Class 1 Voltage 10-30v Mounting Type 3 Hole Fixed 103mm Centre to Centre Brand Roadvision Cable Length 300mm Sheathed Wattage 28w Body Material Aluminium Housing Weatherproofing IP67 Width (mm) 112mm Colour Amber Height (mm) 48mm Flash Pattern 10 Selectable Flash Patterns
